IDEC MICRO/I HG1P-ST32 Series User Manual

4 Popup Screen
5-24 WindO/I-NV4 User’s Manual
4.2 Popup Screen Configuration
■ Title Bar
Displays buttons and the title of the Popup Screen.
Pressing the title bar of the screen allows you to move the screen to the front.
■ (Move) Button
Moves the Popup Screen.
Close ButtonMove Button
Title Bar
Screen Display Area
MICRO/I MICRO/I MICRO/I
When there is a title bar on the popup screen, touch switches that are within 20 dots of the title bar will not
respond.
1
Press
2
Touch the position where the
screen will be moved to
3
The screen will move the position
that was touched
MICRO/I MICRO/I MICRO/I
The location that was touched will
become the location of
.
• The Popup Screen can be moved in the range where the button can be displayed.
• The Popup Screen will be moved in units of 1 dot.
