5 Screen Restrictions
5-26 WindO/I-NV4 User’s Manual
5.1 Screen Number
The number of screens and layered screens that can be created in a single project and the number of Popup Screens
that can be displayed on the Base Screen are as follows:
■ Base Screen
■ Popup Screen
5.2 Maximum Number of Parts
■ Number of Parts That Can be Placed on a Single Screen
■ Number of Parts That Can be Displayed on a Single Screen
In addition to the currently displayed Base Screen, this includes layered screens and currently displayed Popup
Screens.
*1 The maintenance screen is not included.
5 Screen Restrictions
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
Item Number of screens
Number of screens that can be created 3,000 max.
Number of layered screens 5 max.
Item Number of screens
Number of screens that can be created 3,015 max.
Number of screens that can be displayed on the Base Screen
3 max. (Including the Device Monitor
*1
)
Screen Number of Parts
Base Screen 960 max.
Popup Screen 480 max.
Parts Number of Parts
Alarm List Display, Alarm Log Display Limit to 1. Either one but can't be both.
Numerical Inputs and Character Inputs in a constant state of input Limit to 1. Either one but can't be both.
Potentiometer 32 max.
Numerical Input 256 max.
Character Input 256 max.
Video Display 1 max.
