IDEC MICRO/I HG1P-ST32 Series User Manual

WindO/I-NV4 User’s Manual 11-63
4 Meter
11
Charts
4.1 How the Meter is Used
The meter displays the value of a word device as the movement of a needle.
• Display the value of a word device in a meter
4Meter
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
External device
MICRO/I
D100 :
0
D100 :
75
0 100
20 80
40 60
0 100
20 80
40 60
