WindO/I-NV4 Users Manual 4-61
3 Project Settings Dialog Box
4
Project Settings
3.9 External Memory Device Tab
The External Memory Device tab is used to configure the destination folder on the external memory device
*1
inserted in the MICRO/I.
External Memory Device Folder
Enter the folder name for the folder to use on the MICRO/I within 8 alphanumeric characters using upper-case
alphabetic characters (A to Z) and numbers (0 to 9). (Default: HGDATA01)
All the data sampled with the log functions is saved in this External Memory Device folder. For details on the external
memory device, refer to Chapter 31 “1 External Memory Devices” on page 31-1.
Remove Files
Select this check box to erase the files saved in the External Memory Device folder.
*1 SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash drive for HG2G-5T and HG1G/1P
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
You cannot use the following characters in the folder name.
. \ / : * ? “ < > |
After operation starts, the folders created in the External Memory Device folder and the file names cannot
be changed.
All Screenshots: Select this check box to erase all the screenshots in the “CAPTURE” folder.
All Alarm Log files: Select this check box to erase all the Alarm Log data saved in the "ALARMLOG" folder.
All Data Log files: Select this check box to erase all the Data Log data saved in the "DATALOG" folder.
All Operation Log files:
Select this check box to erase all the Operation Log data saved in the “OPERATIONLOG”
folder.
Trigger Device Address: Specifies the bit device or the bit number of the word device to serve as condition to
delete the files.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-68.
