WindO/I-NV4 User’s Manual 31-1
31
External Memory Devices
This chapter describes the specifications, functions, and notes to observe when using external memory devices with
the MICRO/I.
1.1 Supported External Memory Devices
External memory device such as the SD memory card and the USB flash drive are used on the MICRO/I interface. The
supported external memory device is different for each MICRO/I model.
1.2 What Can Be Done Using an External Memory Device
The following functions are available when an external memory device is inserted in the MICRO/I.
*1 USB2.0
*2 This is applicable for models with an audio interface only.
*3 This is applicable for models with a video interface only.
*4 Recording sound function is for HG4G/3G only
*5 The File Copy function is not supported
*6 SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash drive for HG2G-5T and HG1G/1P
Chapter 31 External Memory Devices
1 External Memory Devices
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
External Memory Device
HG5G/4G/3G/2G-V,
HG4G/3G, HG2G-5F
HG2G-5T, HG1G/1P
SD memory card YES NO
USB flash drive
*1
YES YES
Functions
HG5G/4G/3G/2G-V,
HG4G/3G, HG2G-5F
HG2G-5T,
HG1G/1P
Reference
SD memory card USB flash drive USB flash drive
Screenshot YES NO YES
Page 8-58
Page 12-27
Alarm Log output YES NO YES Page 13-20
Data Log output YES NO YES Page 14-19
Reading/writing recipe data YES NO YES Page 18-10
Displaying picture files YES NO YES Page 2-29
Playing sound files
*2
YES NO NO Page 21-7
Recording video camera images and microphone
sounds
*4
.
*3
YES NO NO Page 22-1
Playing movie files
*3
YES NO NO Page 22-1
Transferring projects and PLC programs, copying
files
YES YES
YES
*5
Page 29-1
USB Autorun function NO YES YES Page 31-22
USB Popup Screen function NO YES YES Page 31-37
Displaying Custom Web Page
*6
YES YES YES Page 28-14
