3 Pie Chart
11-52 WindO/I-NV4 User’s Manual
3.1 How the Pie Chart is Used
The stacked bar chart and pie chart are used to show the proportion of individual data to the sum of the data.
They can be used to check the relative change in multiple values of device addresses in real-time.
• Display the proportion of the sum of multiple values of device addresses in a stacked bar chart or a pie chart
3Pie Chart
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
External device
MICRO/I
1 : 1 : 1
4 : 2 : 1
D100 :
10
D200 :
10
D300 :
10
D100 :
120
D200 :
60
D300 :
30
If the source data is all 0, the chart shows the same proportion for all the data.
