IDEC MICRO/I HG1P-ST32 Series User Manual

3 Global Script
20-16 WindO/I-NV4 User’s Manual
A Global Script operates for the entire project. The scripts are executed in order on the list and in accordance with the trigger
conditions after the parts on the MICRO/I screen are processed. A maximum of 16 Global Scripts can be set to a project.
3.1 Setting procedures for Global Script
Global Script is setup using the following procedures.
1 On the Configuration tab, in the System Setup group, click Global Script.
The Global Script Settings dialog box is displayed.
2 Under Settings, select the script ID to configure, and then click Edit.
The Global Script dialog box is displayed.
3 On the General tab, select the Use Global Script check box.
3Global Script
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
With Global Script, you cannot do indirect read and indirect write of the external device address.
For details about the indirect read and indirect write, refer to Chapter 2 “Indirect Read and Indirect Write
Settings” on page 2-5.

IDEC MICRO/I HG1P-ST32 Series Specifications

General

Brand	IDEC
Model	MICRO/I HG1P-ST32 Series
Category	Control Panel
Language	English
