5 Script Coding Examples
20
Script
Script
Operation description
Converts the decimal numeric value in LDR200 to a string and stores it in order with LDR100 as the starting address number.
Converting 1234 (when the data type is UBIN16(W))
Converting -12345 (when the data type is BIN16(I))
Converting 1234567890 (when the data type is UBIN32(D))
Converting -1234567890 (when the data type is BIN32(L))
■
Example 5.7.20 Convert decimal to string
DEC2ASCII([LDR 100], [LDR 200]);
• This function can be used with data types UBIN16(W), BIN16(I), UBIN32(D), BIN32(L), BCD4(B), and
BCD8(EB).
• Only internal devices can be used.
• When using functions that handle strings, check the Storage Method of string data setting on the
System tab in the Project Settings dialog box. Depending on the setting, the upper and lower bytes
are stored in the reverse of the following explanation.
For details, refer to Chapter 4 “3.1 System Tab” on page 4-25.
• A NULL terminating character (0x00) is added to the end of the string.
Device address
Stored value
Device address Stored value Upper byte Lower byte
23x0 = '2'13x0 = '1'LDR1004321LDR200
LDR101 '3' = 0x33 '4' = 0x34
LDR102 0x00 0x00
Terminating character
Terminating character
Device address
Stored value
Device address Stored value Upper byte Lower byte
13x0 = '1'D2x0 = '-' LDR10054321-LDR200
LDR101 '2' = 0x32 '3' = 0x33
LDR102 '4' = 0x34 '5' = 0x35
LDR103 0x00 0x00
Terminating character
Device address
Stored value
Device address Stored value Upper byte Lower byte
LDR200
LDR201
1234567890
LDR100 '1' = 0x31 '2' = 0x32
43x0 = '4'33x0 = '3'LDR101
LDR102 '5' = 0x35 '6' = 0x36
LDR103 '7' = 0x37 '8' = 0x38
LDR104 '9' = 0x39 '0' = 0x30
LDR105 0x00 0x00
Terminating character
Terminating character
Device address
Stored value
Device address Stored value Upper byte Lower byte
LDR200
-1234567890
LDR100 '-' = 0x2D '1' = 0x31
33x0 = '3'23x0 = '2'LDR101LDR201
LDR102 '4' = 0x34 '5' = 0x35
LDR103 '6' = 0x36 '7' = 0x37
LDR104 '8' = 0x38 '9' = 0x39
LDR105 '0' = 0x30 0x00
Terminating character
Terminating character
