WindO/I-NV4 User’s Manual 24-27
4 Clear
24
Online Function
4.2 Deleting Data from an External Memory Device Inserted in the MICRO/I
1 Change communication settings according to the connection method between the computer and the MICRO/I.
In the Communication Settings dialog box, select MICRO/I from Communicate with. For details, refer to “1.3
Change Communication Settings” on page 24-5.
2 Open project data.
3 On the Online tab, in the MICRO/I group, click Clear, then click Stored Data in External Memory Device.
The Clear Data dialog box is displayed.
4 Select the check box for the data items to be deleted from the External Memory Device folder.
Screenshot, Alarm Log files, Data Log files, Operation Log files, and Recipe Files
5 Click OK.
•When Communicate with is set to MICRO/I and Port to USB, deletion of the data starts.
•When Communicate with is set to MICRO/I and Port is set to Ethernet, the Target IP Address dialog box is
displayed. Specify the IP address of the MICRO/I, and then click OK to start deletion of the data. For details, refer
to “To execute any function except project data download” on page 24-10.
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
If security is enabled in the MICRO/I project, the Password Screen is displayed. Enter the password.
For details, refer to Chapter 23 “User Accounts and the Security Function” on page 23-1.
To Next Page
