1 Monitoring with WindO/I-NV4
25-2 WindO/I-NV4 User’s Manual
• Checking the state of external devices connected to the MICRO/I
• Displaying the value of device address in a popup
• Highlighting objects while satisfying conditions
Object List window Script Editor
Computer
MICRO/I
130
Disconnect
Connect
External device
External device
External Device Monitor
External Device ID: 0
External Device ID: 1
External Device ID: 0
External Device ID: 1
Popup
Popup
Highlighted
Trigger Condition
While satisfying the condition: LM0==1
LM0 =
0 1
Condition
Condition
Not satisfiedNot satisfiedNot satisfied
SatisfiedSatisfiedSatisfied
