2 Using the Simulator
26-6 WindO/I-NV4 User’s Manual
5 Select the loading method of the project data and click OK.
■ Load Saved Value of Device Address (External Device, LK, LKR)
The saved values of device addresses on the external device, HMI keep relays (LK), and HMI keep registers (LKR) will
be loaded when the project data is loaded.
■ Clear Saved Value of Device Address (External Device, LK, LKR)
The saved values of device addresses on the external device, HMI keep relays (LK), and HMI keep registers (LKR) will
be cleared when the project data is loaded.
6 Repeat steps 1 to 5, and click when you have finished debugging.
This terminates the simulator.
2.3 Saving the Displayed Screen as an Image
You can save the screen displayed on the simulator as an image.
1 Click Capture.
The Save As dialog box is displayed.
2 Select the save location, enter a File name, and then click Save.
