WindO/I-NV4 User’s Manual 28-21
2 FTP Server Function
28
Maintenance
● FTP Server Function Configuration Procedure
1 On the Configuration tab, in the System Setup group, click Project.
The Project Settings dialog box is displayed.
2 Configure the items on the FTP Server tab.
■ Enable FTP Server function
When the Enable FTP Server function check box is not selected, you cannot access the folder of the external
memory device inserted in the MICRO/I even when the connection from the FTP client to the IP address of the
MICRO/I has been established.(Default: Off)
■ Port Number
Specifies the port number to use for the FTP server function (0 to 65535). (Default: 21)
■ Connection Timeout
Set the timeout period. After you login MICRO/I, MICRO/I will keep monitoring for its traffic. If there is no traffic at all
for a specified period of time, the MICRO/I will disconnect the FTP client. (Default: 15 minutes)
■ Specify Target
Specify the folder and the external memory device inserted in the MICRO/I to be accessed from the FTP client. When
the Target is specified, you cannot access the level higher than the specified folder.
3 Click the OK button.
• The timeout period to login the MICRO/I is 1 minute.
•If Device Address is selected for (Data Type), note the following points:
- When the value of device address is 0, the Connection Timeout is 1 minute, and when the value of
device address is 61 or more, the Connection Timeout is regarded as 60 minutes.
- Once a network connection is established between the FTP client and the MICRO/I, the timeout period
cannot be changed. The timeout period needs to be set in Device Address before connecting the FTP
client to the MICRO/I.
When you access a file during its reading or writing operation, the reading or writing operation for the file
accessed is performed after the first processing is completed.
To Next Page
