WindO/I-NV4 User’s Manual 30-29
5 Module Configuration Dialog Box
30
Expansion Modules
This section describes the Module Configuration dialog box to configure the settings for the expansion module.
5.1 Overview
The MICRO/I is capable of using the expansion modules described in “1.2 Applicable Expansion Modules” on page 30-
2. To use an expansion module, insert the expansion module to be connected to MICRO/I on the Module
Configuration dialog box.
●
Module Configuration Dialog Box
The module configuration can be created by selecting the expansion modules to use in the expansion modules list and
dragging and dropping them to the module configuration area.
5 Module Configuration Dialog Box
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
Module Configuration Area: Displays the configuration of connected expansion modules.
Expansion Module List: Displays a list of expansion modules that can be connected to the MICRO/I.
Parameter Reference Area: Displays the parameters that are configured for the expansion modules.
Parameter Reference Area Expansion Module List
Module Configuration Area
