3 HG2G-5T, HG1G
35-56 WindO/I-NV4 User’s Manual
3 Press the [X] to close the Adjust Brightness Screen.
● Adjusting the Touch Panel
A gap may be caused in the operation accuracy of the touch panel by the secular distortion, etc. Adjust the touch
panel according to the following procedure when there is a gap in the operation of the touch panel.
1 Press the Main Menu on the Top Page in System Mode. The Main Menu Screen appears.
2 Press in order of Initial Setting, Initialize, TP Adjust. The confirmation screen appears and asks “Adjust Touch
Panel setting?”. Press Yes, then the Touch Panel Adjust screen appears.
3 Press the center of the X mark, then the position of the mark changes one after another. Press five marks
sequentially.
4 When normally recognized, the confirmation screen of 2
is restored.
At procedure
3, when pressing a point away from the center of the X mark, a recognition error will result. Then the X
mark returns to the initial position, then repeat the procedure of 3 again.
To adjust the brightness in the System Mode, use the [<<] and [>>] buttons located at the bottom of the
Top Page.
Run Offline MainMenu
<< >>
SYSTEMMODETOPPAGE
2010/OCT/14/THU14:56:44
IPAddress192.168.0.1(DHCP)
BRIGHTNESS16
Run Offline MainMenu
<< >>
SYSTEMMODETOPPAGE
2010/OCT/14/THU14:56:44
IPAddress192.168.0.1(DHCP)
BRIGHTNESS16
Pressthecenterofthesymbol.
Press the center of the X mark.
This will ensure the accuracy of the touch panel operation.
