WindO/I-NV4 User’s Manual A-3
2 View Browser
Appendix
The View Browser displays the list of graphics that have been prepared in advance in WindO/I-NV4. The settings
displayed on View Browser vary based on the parts.
These graphics can be used as the outline of parts.
Example: Bit Button
■ Type
Selects the category of graphics.
■ OFF, ON
Displays the graphic when OFF or ON. Click ON or OFF to switch the graphics displayed on the list.
■ Picture List
Displays the list of registered graphics. Select the graphic to use as the outline of the part.
2 View Browser
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
