WindO/I-NV4 User’s Manual 3-77
5 User Communication
3
Communication
Skip
The data with the specified number of bytes in the receive data will be ignored.
This can be configured only when RXD is selected as Type on the Command Settings dialog box, and Skip is
selected under Type on the Data Settings dialog box.
■ Number of bytes
Specify the number of bytes (1 to 249) of receive data to be ignored.
Example: Skip for receive command data
In the received four byte data (1 (31h), 2 (32h), 3 (33h), 4 (34h)), only the data for 3 (33h) and 4 (34h) is received
and the two bytes of 1 (31h) and 2 (32h) are discarded.
Item Setting
Number of bytes 2
Enabled data
4
(34h)
3
(33h)
2 bytes
(Ignored)
Received data
1
(31h)
2
(32h)
3
(33h)
4
(34h)
Order of reception
