WindO/I-NV4 User’s Manual 4-77
3 Project Settings Dialog Box
4
Project Settings
â– Compatible with HG1B
These options are only displayed when the Use HG1B Compatible functions check box is selected in the
WindO/I-NV4 Options dialog box, on the General tab, under Compatibility.
Parts:
Expand display area of text for parts placed on the Top Layer:
Select this check box to draw text even when a part of the text is located outside of the part.
However, if the text too far outside the outline of the part, it may not be drawn.
Align the text area (Character Input/Message Display/Numerical Input/Numerical Display):
For characters displayed in Numerical Input, Character Input, Message Display, and Numerical
Display, select this check box to align characters based on the area of maximum displayable
character length.
Write NULL terminating character (0x00) as the end of string when string which Digits is maximum is input
(Character Input):
Select this check box to write a NULL character (0x00) at the end character when a string of the
maximum length has been input.
Show Arithmetic Error when the Minimum, Maximum or Limits is invalid (Bar Chart, Line Chart, Meter):
Select this check box to display the Processing error when the following values are invalid.
Bar Chart, Line Chart: Minimum, Maximum
Meter: Minimum, Maximum, Limits for the range
Word Button/Word Write Command:
Write the data as 2 words: Select this check box to write the calculated result of arithmetic
operations (+, -, *, /) as two words when UBIN16(W) or
BIN16(I) is selected for Data Type. For +, -, *, /, the calculated
result is written in two words as a 32-bit numeric value.
For "/" (division), the quotient data is written in the first word, and
the remainder data is written in the second word.
Clear this check box to write the result of arithmetic operations as
one word.
Numerical Input/Numerical Display:
Divide Floating data and Integer data: Select this check box to read and display the decimal portion of
data and the integer portion of data from different device
addresses when BCD4(B) or BCD8(EB) is selected for Data
Type.
Message Display:
Ignore LF code in the variable strings: Select this check box to display messages by ignoring the linefeed
code LF (0Ah) when displaying text according to values of device
addresses.
Clear this check box to display messages with line breaks using the
linefeed code LF (0Ah).
Convert NULL code to Space code in the variable strings:
Select this check box to display messages by converting the NULL
terminating code (00h) to a space (20h) when displaying text
according to values of device addresses.
Clear this check box to terminate messages with the NULL
terminating code (00h).
Timer:
Keep Timer status after changing the screen: Select this check box to continue the timer count when switching
the base screen or when displaying a popup screen.
