WindO/I-NV4 User’s Manual 7-7
1 Shapes
7
Drawings
■ Size
■ Place on the Top Layer
Select this check box to display the polygon on the top layer. The polygon will have precedence when other drawings
and parts are overlapping with it. For details, refer to Chapter 6 “4 Drawings and Parts Overlapping” on page 6-5.
W, H: Specifies the size of the polygon in width and height.
W: 1 to (base screen horizontal size)
H: 1 to (base screen vertical size)
Width
Height
Screen
Polygon
