4 Print Button
8-60 WindO/I-NV4 User’s Manual
The methods to erase screenshot files saved on the external memory device are as follows.
• To erase files during operation using parts, on the External Memory Device tab on the Project
Settings dialog box, select the Remove Files check box and the All Screenshot data check box, and
then configure the trigger device address. Assign that trigger device address to a part.
• To erase files with WindO/I-NV4, click Clear on the Online tab, and then click Stored Data in External
Memory Device to open the Clear Data dialog box. Select the Screenshot Data check box and click
OK.
• To erase files on the HG5G/4G/3G/2G-V, HG4G/3G and the HG2G-5F, go to the System Mode - File
Manager. In the File Manager, select the files to be deleted by pressing DEL.
