WindO/I-NV4 User’s Manual 10-67
3 Picture Display
10
Data Displays
Specify from Picture dialog box
To specify the center point that will serve as the pivot point for rotation, perform one of the following operations. For
the coordinates, the X-coordinate and Y-coordinate of the center point are displayed with the center of the picture as
the origin.
• Double-click on the displayed picture.
• Select and drag the mark indicating the center point or move with the cursor key.
Center Point
Point
