3 Configuration & Functions
2-48 WindO/I-NV4 User’s Manual
■ Editing
■ Project
Command Description
Arrange
Bring to Front Moves the selected object to the front.
Send to Back Moves the selected object to the back.
Group Groups multiple objects.
Ungroup Cancels the group.
Align
Align Left Aligns selected objects to the left.
Align Center Aligns selected objects to the center.
Align Right Aligns selected objects to the right.
Align Top Aligns selected objects to the top.
Align Middle Aligns selected objects to the middle.
Align Bottom Aligns selected objects to the bottom.
Make Horizontal
Spacing Equal
Aligns selected objects to be equally spaced horizontally.
Make Vertical Spacing
Equal
Aligns selected objects to be equally spaced vertically.
Rotate
Rotate Right 90° Rotates selected drawing objects 90° to the right.
Rotate Left 90° Rotates selected drawing objects 90° to the left.
Flip Vertical Flips selected drawing objects vertically.
Flip Horizontal Flips selected drawing objects horizontally.
Replace
Automatically replaces a specified device address with a separate device
address.
Select Selects objects in the editing window.
AutoResize
Automatically changes the text size to the object’s size and display region.
A specific value is added to the device address number of the object
when pasting and duplicating parts.
Increment Bit Number
Enables or disables the increment bit number function.
A specific value is added to the bit number of the object when pasting
and duplicating parts.
Command Description
Download
Project Data Downloads project data to the MICRO/I.
Files to External Memory
Device
Stops the MICRO/I and then downloads files to the external memory
device inserted in the MICRO/I. The MICRO/I resumes running when files
have finished downloading.
Files to External Memory
Device while running
Downloads files to the external memory device inserted in the MICRO/I
without stopping it.
Upload
Project Data Uploads project data from the MICRO/I.
Stored Data in External
Memory Device
Uploads data from the External Memory Device folder for the currently
running project.
Compare
Compare Projects
Compares the screen data and scripts in an existing project with the
project data currently being edited and displays the results of that
comparison.
Re-verify Updates the comparison results to the most latest state.
Target Info.
Displays version information for the MICRO/I system software and project
information.
Comm.Setup
Configures the communication target and communication conditions
between the target and the MICRO/I or between the computer and the
MICRO/I.
