1 Bar Chart
11-16 WindO/I-NV4 User’s Manual
■ Comment
Used for entering comments about trigger conditions. Maximum number is 80 characters.
■ While not satisfying the condition
Selects operation of the Bar Chart when condition is not satisfied.
Not display Chart data: The plate and flange are displayed, but Bar Chart is not displayed.
Not update Chart data: The last updated Bar Chart is displayed. The Bar Chart does not change.
