WindO/I-NV4 User’s Manual 11-59
3 Pie Chart
11
Charts
● Options Tab
The Options tab is displayed in Advanced mode.
■ Place on the Top Layer
Select this check box to display the parts on the top layer. The parts will have precedence when other drawings and
parts are overlapping with it. For details, refer to Chapter 6 “4 Drawings and Parts Overlapping” on page 6-5.
