WindO/I-NV4 User’s Manual 14-15
3 Data Log Settings Dialog Box
14
Data Log Function
■ Sampling Method
Sets the method that will be used by the MICRO/I to read the values of device addresses.
Always: The values of the device addresses set for the data of
each channel are always read. When the condition of
writing to the data storage area is satisfied, the values
that were read at that point in time are written to the
data storage area.
While satisfying the condition of writing to data storage area: The values of the device addresses set for the data of
each channel are read when the condition of writing to
the data storage area is satisfied, and those values are
written to the data storage area.
The total number of words of data that can be registered to the data log settings will depend on Sampling
Method.
•If Sampling Method is Always, the total number of words in all channels is 128 words or less.
•If Sampling Method is While satisfying the condition of writing to data storage area, the total
number of words per channel is 128 words or less.
