5-4-10- Adjustment of probe reference position
WARNING:
RISK DUE TO ARM MOVEMENT
This operation must only be performed by a user specially trained by Technical
Services.
The pipetting arm will move with the lid open during this operation.
Contact with the moving pipetting arm may cause severe injuries.
The reference position of the probe must be adjusted each time the needle is replaced, or when requested by
the Technical Services.
This operation is considered as a particular use of the analyser and must be performed only by a user specially
trained to this process.
The different probe positions are defined in relation to this reference position , located to the left of the rinsing
well.
Adjustment must be defined for the three dimensions of the analyser’s functional plane (XYZ adjustments).
!
It is essential that each position be adjusted for the three dimensions.
Inappropriate adjustments may decrease the level of analytical performance.
Perform this procedure only at the request of IDS Technical Service & Support personnel.
Depending on whether the locking system is present or not, the procedure is different. The operations to be
performed in each case are described in two different procedures.
If the lid is not equipped with a locking system, refer to the procedure described in chapter 5-4-10-1-
Adjustment procedure for analyser without lid locking system, page 133.
If the lid is equipped with the locking system, the activation key provided with the analyser’s accessories will
be used in this procedure. Refer to the procedure described in chapter 5-4-10-2- Adjustment procedure for
analyser with lid locking system, page 136.
WARNING:
USE OF THE ACTIVATION KEY
The activation key allows a particular use of the analyser, without user’s protection
against the pipetting arm movements. The pipetting arm will move with the lid
opened.
Contact with the moving pipetting arm may cause severe injuries.
The use of the activation key is strictly restricted to this adjustment procedure.
Maintenance
5-4- Analyser Interventions (continued)
IDS-iSYS User Manual - Revision M1!
Maintenance 5-4
132
Software version V 14
