2-3-4- MAINTENANCE menu (continued)

Used only at the request of IDS Technical Services & Support:

allows the user to deactivate a washer module or a speciﬁc

wavelength in case of failure.

Displays the analyser status (see Section 2-2, page 21).

User Interface Software
