If positive identification has failed, the rail position is displayed in orange with “???” instead of
the removable tray representation.
•
Should identification fail, repeat the procedure for putting the sample tray in position.
•
If the rail is still not identified, the tray must be identified via the user interface.
!
If a barcode of one of the samples installed on the removable tray contains a %character the
tray is not identified and the rail position is displayed in orange with «???».
In this case, remove the relevant sample from the tray, then place it again at its position with its
barcode label facing inwards. Once the removable tray is installed into the compartment, this
sample must be identified using the keyboard.
Configure a tray
•
Click on the tray position:
•
Select in the corresponding dialog boxes the type and number of the tray.
•
Click on .
The corresponding tray is displayed on the interface, with each position considered to be occupied but not
identified. The software opens a window which allows the positions to be identified:
•
Next, identify the occupied positions (see Identify the positions of the tray without barcode reading, page
63).
Use
3-6- Loading of Calibrators, Controls or Samples in the Sample Compartment (continued)
IDS-iSYS User Manual - Revision M1!
Use 3-6
62
Software version V 14
