Inovance MD800 Series Function Guide

Function Applications
-517-
4.6.4 Overheat Protection
Related Parameters
Para. No. Name
Default
Value Range Description
F9-57
Motor overheat
protection
threshold 1
110°C 0°C to 200°C
When the motor temperature measured by the
sensor connected to the hardware source
mapped to AI1 exceeds the value of F9-57
(motor overheat protection threshold 1), the
AC drive reports a motor overtemperature fault
(E45.00) and acts according to F9-53 (fault
protection action selection 6).
F9-58
Motor overheat
pre-warning
threshold 1
90°C 0°C to 200°C
When the motor temperature measured by the
sensor connected to the hardware source
mapped to AI1 exceeds the value of F9-58
(motor overheat pre-warning threshold 1) and
the function of the DO terminal is set to 9
(motor overtemperature), the DO terminal
outputs an active signal.
F9-59
Motor overheat
protection
threshold 2
110°C 0°C to 200°C
When the motor temperature measured by the
sensor connected to the hardware source
mapped to AI2 exceeds the value of F9-59
(motor overheat protection threshold 2), the
AC drive reports a motor overtemperature fault
(E45.00) and acts according to F9-53 (fault
protection action selection 6).
F9-60
Motor overheat
pre-warning
threshold 2
90°C 0°C to 200°C
When the motor temperature measured by the
sensor connected to the hardware source
mapped to AI2 exceeds the value of F9-60
(motor overheat pre-waring threshold 2) and
the function of the DO terminal is set to 9
(motor overtemperature), the DO terminal
outputs an active signal.
F9-61
Motor overheat
protection
threshold 3
110°C 0°C to 200°C
Motor overheat protection threshold 3 When
the motor temperature measured by the
sensor connected to the hardware source
mapped to AI3 exceeds the value of F9-61
(motor overheat protection threshold 3), the
AC drive reports a motor overtemperature fault
(E45.00) and acts according to F9-53 (fault
protection action selection 6).
F9-62
Motor overheat
pre-warning
threshold 3
90°C 0°C to 200°C
Motor overheat pre-warning threshold 3 When
the motor temperature measured by the
sensor connected to the hardware source
mapped to AI3 exceeds the value of F9-62
(motor overheat pre-waring threshold 3) and
the function of the DO terminal is set to 9
(motor overtemperature), the DO terminal
outputs an active signal.
