Function Applications
-461-
it is skipped automatically when other parameters are set on the local operating panel, and a write
failure is reported when this hardware source is assigned to other parameters at the background or
by using an external operating panel.
For example, if F4-00 (DI1 hardware source) is set to 002, pressing the UP key will automatically skip
002 to 003 when you set F4-02 (DI2 hardware source).
3. If one device in a device group selects a DIO of the power supply unit as the input terminal (DI)
source, the DO terminals of all devices in the group cannot select this DIO as the hardware source. If
a DIO has been selected as the hardware source of a DI, this DIO is automatically skipped when you
set hardware resources for DOs on the local operating panel, and a write failure occurs when this DIO
is selected as the hardware source of a DO at the background or by using an external operating
panel.
Similarly, if one device in a device group selects a DIO of the power supply unit as the output
terminal (DO/RO) source, the DI terminals of all devices in the group cannot select this DIO as the
hardware source. If a DIO has been selected as the hardware source of a DO, this DIO is
automatically skipped when you set hardware resources for DIs on the local operating panel, and a
write failure occurs when this DIO is selected as the hardware source of a DI at the background or by
using an external operating panel.
For example:
If F4-00 (DI1 hardware source) is set to 005, pressing the UP key will automatically skip 001 to 002
when you set F5-02 (DO2/RO2 hardware source).
If F5-00 (DO1/RO1 hardware source) is set to 001, pressing the UP key will automatically skip 005 to
006 when you set F4-00 (DI1 hardware source).
4.3.1.2 Functions of DI Terminals
The AC drive is equipped with eight multi-function DI terminals, each of which can be assigned with a
DI function. Note that the functions of the eight DIs of the same device cannot be duplicate.
Table 4–16 DI-related parameters
Para. No. Name
Default
Value Range Description
F4-01
DI1 function
1
0 to 63
For details about DI1
terminal function selection,
see
Table 4–17 DI
function description
on
page 462
.
F4-03
DI2 function
4
F4-05
DI3 function
12
F4-07
DI4 function
13
F4-09
DI5 function
0
F4-11
DI6 function
0
F4-13
DI7 function
0
F4-15
DI8 function
0
F4-19
DI1 delay
0.0s 0.0s to 3600.0s
These parameters define
the delay of the DI terminal
state change.
The delay setting function is
available only for DI1, DI2,
and DI3 currently.
F4-20
DI2 delay
0.0s 0.0s to 3600.0s
F4-21
DI3 delay
0.0s 0.0s to 3600.0s
