Insightec Exablate 2100V1

To Next Page

To Previous Page

SYSTEM OVERVIEW

Manual Part Number

● Number of phases: Input 3-phase (5 wire)

● Rated power frequency: 50/60Hz

● Rated power input: ~10Kva

● Protection against electric shock: Applied Part Type BF

◼ Exablate Table Specifications:

● Dimensions (L x W x H): 231±1 x 65±1 x 110.5±1 cm

● Height in lowest position: 90cm

● Weight: 230Kg

◼ Cleaning and High-Level Disinfection Cart Specifications:

● Dimensions (L x W x H): 80±1 x 58±1 x 118±1 cm

● Net weight: 25Kg

● Full weight (with liquids): 39Kg
