Micromate Operator Manual – 721U0201 Revision 6 53
Setup Menus Continued
11.1. View/Edit Current Setup
The View/Edit Current Setup menu allows you to configure the Micromate to monitor and record
data from a geophone and or microphone in different record modes and at different sample rates.
The Micromate can be set to trigger at a specific level before it will record data or data can be
recorded as soon as it enters monitor mode. The data can be recorded in two formats; waveform
and histogram. The event records can vary in length and include the Location, Client, Company,
General notes, Job Number, Scaled Distance and GPS location. The Micromate can also control two
outputs or monitor one input.
View/Edit Current Setup Menu Highlighted
Options Available under Current Setup
11.1.1. Active Sensors
This menu allows you to select which sensor(s) will be active when the Micromate is in monitoring
and recording data. The options are Geophone and Microphone, Geophone only or Microphone
only. The factory default setting is for both geophone and microphone to be active.
