Micromate Operator Manual – 721U0201 Revision 6 35
9.1.11. Save Icon
The Save icon will be displayed and allow any changes made to the current settings to be saved. It
will also be displayed in the Event List menu if a memory stick has been inserted in the USB port.
This allows for the saving of event data to the USB memory stick.
Save Changes to Setup File Save Event Data to USB Memory Stick
9.1.12. Print Icon
Note Printing is only supported when the Micromate is configured for the English language. For
other languages, use a memory stick to copy and transfer the events or connect the Micromate to
the computer directly to print reports using Instantel’s computer software.
The Print icon will only be displayed when in the Event List menu and the supported Citizen® CMP-
30BTU printer has been connected to the Micromate USB port. Select the event(s) to be printed
and press the print icon. Refer to section 9.3.3.c Print Events for additional information.
List of Events Stored on the Micromate
9.1.13. Compass Icon
The Compass icon will only be displayed while event data is being viewed. The blue arrow of the
compass icon indicates the direction in which additional data is available. Moving to the left and/or
right will display the data from the current event. Moving up and down will display the data from
the previous or next event.
