Page #311 background image
January 2007 311
Intel
®
855GME Chipset and Intel
®
6300ESB ICH Embedded Platform Design Guide
Layout Checklist
GCLKIN
Place series resistor close to CK409,
within 500 mils.
Total trace length range is 4 to 9 inches.
Minimum spacing 20 mils.
Overall length of CLK66 is considered the
reference length for all other CLK66 and
CLK33, except USBCLK and CLK14.
The length of CLK66 traces should be
matched within ± 100 mils and then used
as the basis for defining the length of all
other length matched clocks.
Refer to CLK66 clock group routing
guidelines detailed in Section 11.2.1.
RSTIN#
Connect to PCIRST# output of the
6300ESB.
GMCH Decoupling, VREF, and Filtering
HLRCOMP
HLVREF
PSWING
GMCH HLRCOMP signal should be
strapped to 1.2 V via 27.4
Ω ±1%
HLRCOMP resistor with trace impedance
55
Ω ±15%.
HLVREF and PSWING voltage
requirements must be set appropriately for
proper hub interface operation. The case
is similar for HIREF and HIVSWING
signals on 6300ESB.
Refer to Section 8.1.4 for HI specific
voltage requirements and several
options for voltage divider circuits.
HXRCOMP
HYRCOMP
Each signal should be pulled to ground
with a 27.4
Ω ± 1% resistor.
Max trace length to the resistor should be
less than 0.5 inches and should be 18 mils
wide to achieve the characteristic
impedance target of 27.4
Ω.
Maintain 25 mil separation from any
switching signals.
This signal is used to calibrate the
Host AGTL+ I/O buffers
characteristics to specific board
characteristics.
Refer to Section 4.8.3.2 for more
information.
HDVREF[2:0]
HAVREF
HCCVREF
Max length from pin to voltage divider for
each reference voltage should be less
than 0.5 inches.
10 mil traces are recommended.
To provide constant and clean power
delivery to the data, address, and
common clock signals of the host
AGTL+ interface.
Refer to Section 4.8.3.1 for
recommended individual voltage
divider circuits.
Table 149. Intel
®
855GME Chipset GMCH Layout Checklist (Sheet 5 of 6)
Checklist Items Recommendations Comments
