3─119
Map Display Setting
1. Shift Coast Line 1
SETTING
2. Shift Coast Line 2
N0.000’
E0.000’
3. LAT/LON Correction
N0.000’
E0.000’
N 35°00.000’
E140°00.000’
5. LORAN C Correction
7. DECCA Correction
0. EXIT
4. MAP Center Position
6. LORAN A Correction
Correcting Chart Position (Map Display Setting)
Procedures 1 Press [RADAR MENU] key twice.
Press [9] key.
Press [5] key.
Press [5] key.
The Map Display Setting Menu will appear.
There are three methods for correcting the chart
position.
[1] Shift Coast Line 1
Set the correction value by operating the cursor.
1 Press [1] key while the Map Display
Setting Menu is open.
2 Move the cursor to the chart on which
a position is to be corrected, and
press [ENT] key.
3 Move the cursor to the radar video of
which position is to be corrected, and
press [ENT] key.
SETTING (correcting) will be indicated for Shift Coast Line 1.
At this time, MAP SHIFT will appear at the radar display button
29
on page 2-7,
indicating that the position is being corrected.
Cancellation of Shift Coast Line 1
1 Press [1] key while the MAP Display Setting Menu is open.
DELETE (no correction) will be indicated for Shift Coast Line 1.
At this time, MAP SHIFT will disappear from the lower right of the radar display.
To Next Page
