8─47
RX Port
1. GPS
2. DLOG
0. EXIT
3. Depth
AUTO
AUTO
OFF
AUTO
AUTO
AUTO
4. Temperature
5. Wind
6. Current
AUTO
7. Rate of Turn
AUTO
8. Rudder
1. AUTO
2.
COM1 (GPS)
3. COM2 (PC)
4. COM3 (NAV1)
5. COM4 (NAV2)
[IV] Reception Port Setting (RX Port)
Set the number of the port via which signals are received from sensors.
Procedures 1 Open the Equipment Setup Menu.
2 Press [5] key.
The COM Port Setting Menu will appear.
3 Press [4] key.
The RX Port Menu will appear.
4 Select the signal you want to set,
pressing the numeric keys [1] to [6].
The Reception Port Setting Menu for each
signal will appear.
Settable signals
1. GPS
2. DLOG
3. Depth
4. Temperature
5. Wind
6. Current
5 Select which port you want to use for
output.
Types of ports to be used
1. AUTO
2. COM1 (GPS)
3. COM2 (PC)
4. COM3 (NAV1)
5. COM4 (NAV2)
* For AUTO, the initial value will be selected.
Select the number of the port to be used, pressing the numeric key.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
To Next Page
