8─48
8.5 Adjustments
yyyy
yyyy
8
[V] Line Monitor
Serial communication data can be seen on the built-in Line monitor.
Line monitor can be used to make sure that the serial data are received properly.
Procedures 1 Open the Equipment Setup Menu.
2 Press [5] key.
The COM Port Setting Menu will appear.
3 Press [7] key.
The LINE MONITOR menu will appear.
4 Select the Communication port
you want to see, pressing the
numeric keys [1] to [8].
The LINE MONITOR appears.
Refer to the next page for the display.
Each ports on the menu repesets followingconnectors.
COM1(GPS) J3 GPS
COM2(PC) J8 NMEA
COM3(NAV1) J6 AIS/NMEA
COM4(NAV2) J9 AUX (Option)
COM6(NSK/COMPASS) J3 SCANNER
COM7(KEY BOARD1) J4 KEY BOARD
COM8(KEY BOARD2) J9 AUX (Optioon)
Exit 1 Press [0] key.
2 Press [RADAR MENU] key.
The Main Menu will reappear.
LINE MONITOR
1. COM1(GPS)
2. COM2(PC)
0. EXIT
3. COM3(NAV1)
4. COM4(NAV2)
5. COM5(NSK/COMPASS)
6. COM6(
RX)
. COM7(KEYBOARD1)
8. COM8(KEYBOARD2)
To Next Page
