8
─
50
8.5 Adjustments
yyyy
yyyy
8
NA
V Setting
1.
2. GPS ANT
. Location
0. EXIT
0m
0m
Navigator Setting (NA
V Setting)
GPS antenna installation positio
n can be set.
[I]
GPS
Antenna Location Setting (GPS
ANT
. Location)
Set the GPS antenna installation position
.
Procedures
1
Open the Equipment Setup Menu.
2
Press [6] key
.
The NA
V Setting Menu will appear
.
3
Press [2] key
.
The GPS
Antenna Location Menu will appear
.
350
352
Table of Contents
Preface
7
Before Operation
8
Precautions
9
Equipment Appearance
17
Table of Contents
19
Glossary
26
General and Equipment Composition
33
Functions
34
Function of this System
34
Features
35
Configuration
37
1.4 Exterior Drawings
38
General System Diagrams
48
Names and Functions of Control Panel Keys and Functions of Software Buttons
53
Names and Functions of Control Panel Keys
53
Functions of Software Buttons
53
Basic Operation
69
Flow Operation
70
Power on and Start the System
71
Observe and Adjust Video
72
Acquire and Measure Data
72
End the Operation and Stop the System
73
Menu Composition
74
Overview of Menu Structure
74
Basic Menu Operation
75
Preparation
77
Adjust Display Brilliance
77
Adjust Contrast
77
Adjust Operation Panel Brilliance [Panel]
78
Switch Day/Night Mode [Day/Night]
78
Adjust Brilliance of Information on Radar Display
79
Adjust Brilliance of Information on Radar Display (Brilliance Setting)
79
Adjust Sound Volume (Buzzer Volume)
80
Reset Alarm Buzzer [Alarm Ack]
80
Set Display Color
81
Basic Operations
83
Start Transmission [Tx/Prf]
83
Stop Transmission [Stby]
83
Change Range (Observation Range Scale) [Range+/-]
83
Tune
84
Control Sensitivity [Gain/Pl]
84
Suppress Sea Clutter [Auto-Sea]
85
Suppress Rain/Snow Clutter [Auto-Rain]
87
Reject Radar Interference [Ir]
89
Hide/Display Range Rings (Rings)
90
Hide Ship's Heading Line (Hl Off)
90
Hide Graphics Information on Radar Display (Graphic Display)
91
General Operations
92
Move Cross Cursor Mark by Trackball
92
Use Ebls (Electronic Bearing Lines) [Ebl1/2]
93
Set Ebl Operation (Ebl1 /2 Setting)
95
Display Variable Range Markers [Vrm1/Vrm2]
98
Display Parallel Index Lines (Parallel Index Line)
101
Switch Bearing Display Mode [Azi Mode]
109
Switch True/Relative Motion Display Mode [Tm/Rm]
110
Move Own Ship's Display Position [Off Cent]
111
Display Other Ships' Trails [Trails]
112
Switch Pulse Length (Gain/Pl)
115
Expand Targets (Target Enhance)
116
Use Video Process (Process)
117
Zoom
118
Use Marker [Mob]
119
Marking [Mark]
120
Operate Ebl Maneuver Function (Ebl Maneuver)
121
Operate Multi-Function Control [Multi]
124
Operate User Key Switches [User Key 1/2]
126
Operation of Guard Zone [Ata Guard Zone]
128
Radar Alarm (Radar Alarm)
131
Display Own Ship's Track
135
Display Own Ship's Track (Display Own Track)
135
Set Own Ship's Track Data Storage Interval (Own Track Interval)
137
Clear Own Ship's Track Data (Clear Own Track)
138
Cancel Storing of Own Ship's Track Data (Own Track Memory)
139
Display Charts
140
Display Coastline Rom Card Produced by Jrc
140
Display Erc Card
141
Fill Charts (Fill Land Area)
142
Display Navigation Information
143
Display Waypoint Marks (Waypoint Display)
143
Display Navigation Information (Nav Display Setting)
144
Create/Edit Navigation Information (Edit User Map)
145
Set Navigation Information (User Map Setting)
151
Set and Display Geodetic System
158
Operate Performance Monitor (Pm Display)
160
Operation Procedures
160
Applied Operations
166
Set Radar Signal Processing (Process Setting)
166
Set Radar Trails (Radar Trails Setting)
169
Set Cursor (Cursor Setting)
173
Set Screen
174
Set Scanner (Trx Setting)
178
Set Chart Display (Map Setting)
180
Set Loran C (Loran C Correction)
192
Use Function Switch [Func]
193
Operation Procedures
193
Function Setting Menu Items
194
Overview of Function Operations
195
Overview of Stored Function Setting Data
198
Personal Information (Pin Setting)
199
Using Card
202
Save in and Transfer to Card (Mem Capa/Copy)
203
Erase/Initialize Card Memory (Clr Mem Init Card)
209
Measurement of Range and Bearing
211
Measurement by Trackball
212
Measurement by Range Rings
213
Measurement by Ebls and Vrms
214
Measurement between Two Optional Points
216
Preparation
221
Collision Avoidance
222
Radar and Collision Avoidance
224
Definitions of Symbols
225
Setting Collision Decision Criteria (Cpa/Tcpa Limit)
227
Setting Vectors (Vector Time)
228
Setting Cpa Ring (Cpa Ring)
229
Setting Automatic Acquisition Key Assignment
230
Setting Automatic Acquisition Key Assignment (Gz Alarm Key Setting)
230
Set Gz Alarm Key
230
Ata Operation
231
Acquiring Target
231
Canceling Unwanted Targets
233
Displaying Target ID No. (Target Number Display)
234
Ata Data Display
235
Target Data Display
240
Alarm Display
244
Lost Target Alarm
246
Gyro Set Alarm
247
Ata Simulation
248
Ais Operation
261
Initial Setting
262
Setting Ais Display Function (Ais Function)
264
Activating Ais Targets
265
Deactivating Ais Targets
266
Setting Ais Symbol Display Function (Ais Symbol Display)
267
Displaying Numeric Data of Ais Targets
268
(Ata Symbol Display)
270
Setting Ata Symbol Display Function
270
Setting Ais Filter (Ais Filter Setting)
271
Same One (Identical Distance)
274
Deciding Ais Target as the same One
274
Conditions for Deciding Ais Target to be Lost
276
Displaying Ais Symbols
277
Ais Alarm Display
278
Restrictions
279
True and False Echoes on Display
281
Radar Wave with the Horizon
283
Strength of Reflection from the Target
285
Sea Clutters
286
False Echoes
287
Display of Radar Transponder (Sart)
290
Maintemance
293
Routine Maintenance
294
Maintenance on each Unit
295
Scanner Unit NKE-2062/2102/2252
295
Display Unit NCD-4340
300
Trouble Shooting and Adjustment
301
Performance Check
302
Check Performance on Test Menu
303
List of Alarms and Other Indications
320
Fault Finding
321
Trouble Shooting
322
Replacement of Major Parts
327
Parts Required for Periodic Replacement
328
Replacement of Lcd Monitor
334
Adjustments
335
Tuning Adjustment
337
Bearing Adjustment
338
Range Adjustment
339
Antenna Height Adjustment
340
Maintenance Menu
356
Vector Constant
364
Adjustment of Nsk Unit to Gyro Compass and Log
368
Setting
370
Mag Compass Setting
373
After-Sales Service
403
Radar Failure Check List
405
Disposal
408
Disposal of the Unit
408
Disposal of Used Batteries
409
Disposal of Used Magnetron
410
Specifications
411
Jma-5206/Hs Type Radar
412
Jma-5210-4/6 Type Radar
413
Jma-5220-7/9 Type Radar
414
Scanner (Nke-2062/Hs)
415
Scanner (Nke-2102)
416
Scanner (Nke-2252-7/9)
417
Display Unit(Ncd-4340)
418
Processor Unit(Ndc-1340)
419
Plotter Unit
421
Ata
423
Keyboard Unit (Nce-7699)
424
Input Enable Signal
425
Output Enable Signal
426
Standard Configuration
427
Others (Option)
429
