JRC JMA-9110-6XA User Manual

JMA-9100 Instruction Manual > 2.CONTROL PANEL KEYS and SOFTWARE BUTTONS> 2.3 FUNCTIONS OF SOFTWARE
BUTTONS
2－19
2
Interference rejection (IR) mode switching
The interference rejection mode is switched whenever this button is clicked.
⇒ ⇒ ⇒ ⇒
Target enhance (ENH) mode switching
The target enhance mode is switched whenever this button is clicked.
⇒ ⇒ ⇒ ⇒
Radar video processing (PROC) mode switching
The radar video processing mode is switched whenever this button is clicked.
⇒ ⇒ ⇒
⇒ ⇒ ⇒
Function (FUNC) mode switching
The function mode is switched whenever this button is clicked.
⇒ ⇒ ⇒
⇒ ⇒
If the button is clicked for 2 seconds, the function registration menu (User Function
Setting) is opened.
,, and Gain, Sea clutter suppression(Sea)、Rain / snow
clutter suppression (Rain), Tune adjustment (Tune)
Adjust the gain, sea clutter suppression, rain / snow clutter suppression and tune using
the track ball.
If the button is clicked on, the adjustment value is shown at the upper-right of the cursor.
Make adjustments by moving the track ball to the left and right. Determine the
adjustment by left-clicking.
, and Sea clutter suppression (Sea) mode, Rain and snow clutter
suppression (Rain) mode, and Tune mode switching
Use these functions to switch to the manual or automatic mode of sea clutter
suppression, rain and snow clutter suppression, and tune. The bar on the left side
indicates the position of the dial.
The mode is switched to (manual) / (automatic) whenever the
button is clicked. If rain and snow clutter suppression is switched to an automatic mode,
sea clutter suppression is switched to an automatic mode also.
2
IR Off IR Low IR Meddle IR High IR Off
3
ENH Off ENH Level1 ENH Level2 ENH Level3 ENH Off
4
PROC Off 3Scan CORREL 4Scan CORREL 5Scan CORREL
Remain Peak Hold PROC Off
5
FUNC Off Coast Deep Sea Fishnet
Storm FUNC Off
6 7 8 9
10 11 12
MAN
AUTO
