JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
3ļ¼59
3
The cursor mode changes to the normal operation mode, terminating the user map delete
mode.
(Example)
3.6.3.7 Batch clearing marks or lines (Clear)
With regard to the created user map, marks or lines are batch cleared by type or by color.
Procedures
1) Open the Edit User Map menu by performing the following menu
operation.
→
The Edit User Map menu will appear.
2)-1 Left-click the item button of
Select the type of marks or lines to be deleted.
To select all types, select .
For example, to delete "red ā—‹" marks, select .
2)-2 Left-click the item button of
Select the color of marks or lines to be deleted.
To select all colors, select .
For example, to clear "red ā—‹" marks, select .
After the items have been selected, Confirmation Window will appear.
The vertex to be deleted
U.Map
2. Edit User Map
7. Delete
by Type
All
ā—‹
7. Delete
All
Red
