JMA-9100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.2 SETTINGS
7.2.11.2 Reception Port Setting (RX Port)
Set the numbers of ports for receiving signals from sensors.
There are two methods for receiving signals: specifying a port for each sensor, or
using the automatic recognition function without specifying ports.
Procedures
1) Open the Serviceman Menu.
2) Perfome the following menu open procedure to open the RX Port
setting menu.
→
→
→
3) Set a port for each sensor.
Settable sensor signals
Heading, Speed, AIS, GPS, DLOG, Alarm, Depth, Temperature, Wind, Current, ROT, RSA,
Time Zone, Date/Time
Selectable ports
When the automatic
recognition function is used:
When the ports are specified:
Behavior pattern of selectable ports
: Data from JRC-LAN is prior
: The system use the port selected by Section 3.12.1 "Receive
Port Setting (RX Port)". The system use data from JRC-LAN
or sensor connected directly.
i
i. In order to set Section 3.12.1 "Receive Port Setting (RX Port)", select in
advance.
: The system use data from sensor connected to the system
directly.
: The system uses data from JRC-LAN.
:
The system uses GPS data from GPS (JRC-LAN connected).
ii
ii. and are selectable signals for Time Zone and Date/Time.
:
The system uses ship's clock data from ship's clock (JRC-LAN
connected)
ii
2. Installation Menu
9. Next
5. LAN Port Setting
2. RX Port
AUTO
Own LAN LAN (GPS) LAN (Ship ’ s Clock)
AUTO
User Setting
User Setting
Own
LAN
LAN (GPS)
LAN (GPS) LAN (Ship’s Clock)
LAN (Ship ’ s Clock)
