JRC JMA-9110-6XA User Manual

JMA-9100 Instruction Manual > 2.CONTROL PANEL KEYS and SOFTWARE BUTTONS> 2.2 NAMES AND FUNCTIONS OF
CONTROL PANEL KEYS
2－15
2
[DATA OFF] (DATA Off) key
This function sets the graphics other than HL, range ring, EBL, and VRM to OFF
temporarily while this key is pressed.
→3.4.11 on page 3-34
[PANEL] (Operator panel brilliance) key
This function adjusts the lighting brilliance of various switches and dial positions on the
operator panel. The brightness changes cyclically whenever this key is pressed.
→3.4.13 on page 3-35
[USER] key
By pressing this key, the signal processing setting that is preset can be called.
The setting changes to FUNC OFF ==> FUNC1 ==> FUNC2 ==> FUNC3 ==>
FUNC4 whenever this key is pressed.
If this key pressed for 2 seconds or more, the function setting menu is displayed.
→3.9 on page 3-111
[OPTION1] key
By pressing this key, the pre-registered menu position can be directly displayed.
At factory shipment, the calling of [Main Menu] is assigned.
→3.8.7 on page 3-103
[OPTION2] key
By pressing this key, the pre-registered menu position can be directly displayed.
At factory shipment, the calling of [Sub Menu] is assigned.
→3.8.7 on page 3-103
Track ball
This function moves the cursor mark to any position. Use this function for setting in
each mode.
Use this function to specify a center position of floating EBL and an off-center position.
→3.3.1 on page 3-14
[Track ball left button]
Use this function to confirm menu selection and numeric value input.
[Track ball right button]
Use this function to reset menu selection and numeric value input.
[BRILL] (Brilliance dial)
This dial is provided at the right of the monitor. Use this function to adjust the brilliance
of the monitor.
→3.2.1 on page 3-6
23
24
25
26
27
28
29
30
31
