JMA-9100 Instruction Manual > 2.CONTROL PANEL KEYS and SOFTWARE BUTTONS > 2.2 NAMES AND FUNCTIONS OF
CONTROL PANEL KEYS
[VRM] (Variable Range Marker) dial
This function changes the range of the VRM that is selected by VRM1/2.
By pressing the dial, the parallel line cursor function can be switched to Operation ā
Fixed ā Off ā Operation.
ā on page 4-6
[Tļ¼R VECT] (True vector display / Relative vector display) key
This function switches the display mode (true/relative) of the tracked target and AIS
target vector.
ā5.1.6 on page 5-14
[TGT DATA] (Target data display) key
This function displays the digital data of the tracked target or AIS target at the cursor
position.
the tracked targetā5.2.3 on page 5-18
the AIS target ā 5.3.5 on page 5-29
[ACQ MANUAL] (Manual acquisition) key
This function enables manual acquisition of the target at the cursor position.
ā5.2.1 on page 5-15
[ACQ CANCEL] (Tracked target cancellation) key
This function cancels the symbol and vector of the target that is being tracked and stops
the tracking of the target.
If this key is pressed for 2 seconds or more, all the targets that are being tracked are
cancelled.
ā5.2.2 on page 5-17
[DAYļ¼NIGHT] (Day/night mode) key
This function switches the color and brightness of the screen that was preset.
ā3.4.12 on page 3-35
[AIS/TT] (AIS On/Off) key
This function switches the AIS function to ON/OFF when the AIS function is enabled.
ā5.3.2 on page 5-27
[HL OFF] (Ship's heading line Off) key
HL (ship's heading highlight line) can be set to Off only while this key is pressed.
ā3.4.10 on page 3-34
