Model 2110

5½ Digit Multimeter Reference Manual Section 3:

Basic DMM operation

2110-901-01 Rev. C/August 2013 3-53

Limits

Limit testing allows you to set high and low limit values. When the reading falls outside these limits,

the instrument beeps and displays the "HI" or "LO" message.

The limit values are stored in volatile memory. The values are reset to zero when the instrument is

turned off. Limits can be used with all measurements (except continuity and diode measurements).

For information on using the USB port as a status indicator for limit testing, see

Pass/fail output from

USB connector (on page C-5).

Front-panel operation

Perform the following steps to use the limits feature:

1. Press the SHIFT and NULL (MATH) keys.

2. Use the ◄ and ► keys to display LIMITS and press ENTER.

3. Set the high and low limits:

a. Use the ◄ and ► keys to display HIGH LIMIT and press ENTER.

Note that if you select the RUN menu option instead, the limits feature will enable using the

present limit values.

b. Use the ◄, ►, ▲, and ▼ keys to set the high limit. Note that the polarity sign can be

toggled between plus and minus. Press the ENTER key.

c. Use the ◄ and ► keys to display LOW LIMIT and press ENTER.

d. Use the ◄, ►, ▲, and ▼ keys to set the low limit and press ENTER.

4. With RUN displayed, press ENTER. The MATH indicator turns on and limit testing starts.

You can disable the math operation by pressing a different function key. You can also disable it from

the math menu as follows:

1. Press the SHIFT and NULL (MATH) keys.

2. Use the ◄ and ► keys to display OFF and press ENTER.
