Keithley 2110 User Manual

Section
3: Basic DMM operation Model 2110 5½ Digit Multimeter
Reference Manual
3-54 2110-901-01 Rev. C/August 2013
Remote operation
Commands that use the <n> parameter can use the MINimum and MAXimum name parameters. MIN
selects the minimum value and MAX selects the maximum value.
Use the following commands to configure and control limit testing:
CALCulate:FUNCtion LIMit Select the limits feature
CALCulate:LIMit:LOWer <n> Set the lower limit
CALCulate:LIMit:UPPer <n> Set the upper limit
<n> = (see Note) Set value (1 µ resolution)
The limit value setting range depends on the selected function. For example, for DCV, the limit value
can be set from -1200 to 1200.
CALCulate:STATe <b> Enable or disable math operations
<b> = 0 or OFF Disable math
= 1 or ON Enable math
mX+b
This math function multiplies a scale factor (m) to the measured reading (X), and then adds an offset
(b). The result of the calculation (y) is displayed on the instrument:
y = mX + b
You can enable this math function and set the values of m and b from the front panel or by using
remote operation. These values are stored in volatile memory and are lost when the instrument is
turned off.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
