Table 2. ABB circuit breaker (product code ABB 1SDH002011A1002_XT5S)
Number of
power
modules
Value DIP switch setting (L)
0.04 0.08 0.16 0.32
4 368 A ON OFF ON ON
3 272 A ON ON ON OFF
2 192 A OFF ON OFF OFF
1 160 A OFF OFF OFF OFF
ON = up, OFF = down
5.2.13.2. Chint circuit breaker
NOTE
Adjust the switches according to the number of power modules in the cabinet.
NOTE
Use the appropriate factor to include the short circuit value in the selected settings.
NOTICE
Adjust the DIP switches carefully to avoid damaging them.
Select the correct values on the DIP switch panel marked lr at the bottom of
the circuit breaker.
Table 3. Chint circuit breaker (product code NM8N-400QEN4003P)
Number of
power mod-
ules
Value DIP switch setting (Ir)
Left Middle Right
4 360 A ON OFF ON
3 280 A OFF ON ON
2 200 A OFF OFF ON
1 160 A OFF OFF OFF
ON = up, OFF = down
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 101 REV 2.40 EN 04-2024
