KEMPOWER Power Unit - Static (S8) - 8 Single Satellites

10.11. Static (S8) – 8 single Satellites
Table 15. S8 connected to 8 single Satellites (8 x 62.5/37.5 A configuration output)
Config.
output
ChargEye con-
nector
Max. current Terminals
DC output Control cable DC input Control cable
1 12 (right) 62.5 A/37.5 A Power Unit 1 Satellite 1
OUT 1 CT 1 CAB 1 CT A
2 22 (right) 62.5 A/37.5 A Power Unit 1 Satellite 2
OUT 2 CT 2 CAB 1 CT A
3 32 (right) 62.5 A/37.5 A Power Unit 1 Satellite 3
OUT 3 CT 3 CAB 1 CT A
4 42 (right) 62.5 A/37.5 A Power Unit 1 Satellite 4
OUT 4 CT 4 CAB 1 CT A
5 52 (right) 62.5 A/37.5 A Power Unit 1 Satellite 5
OUT 5 CT 5 CAB 1 CT A
6 62 (right) 62.5 A/37.5 A Power Unit 1 Satellite 6
OUT 6 CT 6 CAB 1 CT A
7 72 (right) 62.5 A/37.5 A Power Unit 1 Satellite 7
OUT 7 CT 7 CAB 1 CT A
8 82 (right) 62.5 A/37.5 A Power Unit 1 Satellite 8
OUT 8 CT 8 CAB 1 CT A
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 138 REV 2.40 EN 04-2024
