KEMPOWER Power Unit - Dynamic (Ds6) - 3 Double Satellites; Dynamic (Ds6) - 6 Single Satellites

10.5. Dynamic (Ds6) – 3 double Satellites
Table 9. Ds6 connected to 3 double Satellites (6 x 200 A configuration output)
Config.
output
ChargEye
connector
Max. cur-
rent
Terminals
DC output Control cable DC input Control cable
1 12 (right) 200 A Power Unit 1 Satellite 1
OUT 1 CT 1 CAB 1 CT A
2 11 (left) 200 A Power Unit 1 Satellite 1
OUT 2 CT 2 CAB 2 CT B
3 22 (right) 200 A Power Unit 1 Satellite 2
OUT 3 CT 3 CAB 1 CT A
4 21 (left) 200 A Power Unit 1 Satellite 2
OUT 4 CT 4 CAB 2 CT B
5 32 (right) 200 A Power Unit 1 Satellite 3
OUT 5 CT 5 CAB 1 CT A
6 31 (left) 200 A Power Unit 1 Satellite 3
OUT 6 CT 6 CAB 2 CT B
10.6. Dynamic (Ds6) – 6 single Satellites
Table 10. Ds6 connected to 6 single Satellites (6 x 200 A configuration output)
Config.
output
ChargEye con-
nector
Max. cur-
rent
Terminals
DC output Control cable DC input Control cable
1 12 (right) 200 A Power Unit 1 Satellite 1
OUT 1 CT 1 CAB 1 CT A
2 22 (right) 200 A Power Unit 1 Satellite 2
OUT 2 CT 2 CAB 1 CT A
3 32 (right) 200 A Power Unit 1 Satellite 3
OUT 3 CT 3 CAB 1 CT A
4 42 (right) 200 A Power Unit 1 Satellite 4
OUT 4 CT 4 CAB 1 CT A
5 52 (right) 200 A Power Unit 1 Satellite 5
OUT 5 CT 5 CAB 1 CT A
6 62 (right) 200 A Power Unit 1 Satellite 6
OUT 6 CT 6 CAB 1 CT A
