9. UNIT FOOTPRINTS AND CLEARANCES
NOTICE
In addition to the given clearances, obey the cable bending radius if cables are
surface-installed. Increase the clearance if necessary.
The cables to all units are always routed from below the unit.
The AC mains power cables are routed to the charging power unit
from the front or the left side of the unit.
The connection cables to the charging point(s) are routed from
behind or the right side of the charging power unit.
Leave at minimum 1000 mm free space in front of the installed cabinet.
It must be possible to open the door of the unit fully and remove
modules from the rack.
Leave at minimum 200 mm free space between the back of the cabinet
and a solid wall. If possible, we recommend leaving 800 mm accessible
space behind the cabinet, for example by positioning the cabinet's side
toward the wall. Otherwise, if it is necessary to remove the cabinet's
back panel to gain access to the back of the cabinet, the cabinet must
be moved.
Leave at minimum 500 mm free space above the cabinet. If it is
necessary to remove the cabinet's back panel to gain access to the
back of the cabinet, the cabinet's roof element must first be removed.
Leave at minimum approximately 20 mm free space between
the charging power units. A double or triple cabinet is one unit.
Leave at minimum 500 mm free working space in front of the installed
Satellite. It must be possible to open the front panel of the unit fully.
Leave at minimum 500 mm free space above the installed Satellite.
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 120 REV 2.40 EN 04-2024
