5.1.4. Moving and lifting Power Unit Version 3
WARNING
Do not go under the unit when it is lifted.
CAUTION
Use all lifting lugs of the unit when you lift it. Minimum angle of slings 60 degrees.
CAUTION
High center of gravity. Make sure that the cabinet does not fall over.
NOTICE
The maximum tilting angle of the charging power unit is 6 degrees. High center of
gravity.
NOTICE
One cabinet with four power modules weighs approximately 400 kg. Use appropriate
lifting equipment operated by qualified professionals.
NOTICE
Carefully remove the control module, the power distribution module, and the front
panel of the mains module from each cabinet before you lift the unit. This is done to
reduce the weight and make space for installing the cables. Keep the modules clean
and dry.
NOTICE
Make sure that you replace the same serial number card to the same cabinet when
you install or replace control modules. Each cabinet is identified with its unique serial
number in ChargEye.
NOTE
The power distribution module weighs approximately 32 kg.
