5.1.8. Moving and lifting Control Unit
NOTICE
The Control Unit frame weighs approximately 12.5 kg without the charging cable.
The Control Unit is shipped in two boxes, one for the unit and another for
the charging cables. The charging cables are not installed on the unit at the
factory.
The weight of the Control Unit box is less than 15 kg and the weight of the
charging cable box is less than 22 kg so they can be lifted without lifting
equipment.
Figure 37. Lifting the Control Unit
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 65 REV 2.40 EN 04-2024
